Pier-16 Equipment List

Telescope	Sigma 105mm F/1.4 Art Lens Stopped down to F/2.0
Mount	Paramount MX
Camera	Player One Poseidon CMOS Colour Camera
Filter Wheel	ZWO 5 Position 2"
Filters	OSC, RGB, Ha/O3 & S2/O3
Guide Camera	N/A
Guider	N/A
Focuser	Astromechanic Lens Focusing System
Power Control	HitecAstro MHP V4

Telescope

Sigma 105mm ART lens stopped down to F/2,0 for better star shapes. Although you will still have some coma to deal with obviously

This is a very fast F/2.0 system & when used with a CMOS sensor, the longest exposure needed for this pier is 180 seconds

CMOS Camera

The Player One Poseidon CMOS Camera Colour CMOS is one of Sony's new generation zero ampglow sensors. They are super sensitive with very low noise.

We have also added some of the latest generation IDAS filters like the D3, NBZ etc which allows you to perform narrowband imaging with the system

Sony IMX571

Back illuminated CMOS Sensor
23.5x15.7mm
6248x4176pixels
3.76µm

Bayer Matrix Parameters

RGGB

12.82° x 8.57°
7.64 "/px
105mm Focal Length
F/2.8
20º Imaging Horizon Limits
Camera Position Angle: 266°

Recommended sub lengths

	Filter	Bright	Dim
	OSC	10-60s	60-120s
	RGB	30-60s	60-180s
	Ha/O3	60-120s	120-180s
	S2/O3	60-120s	120-180s

Calibration Files

10s Darks
20s Darks
30s Darks
45s Darks
60s Darks
90s Darks
120s Darks
180s Darks
Bias Frames
Flat Frames

The following calibration files are available as standard with this system. Other darks are available upon request.

Recommended sub lengths

Although Pier-11 has a OSC Camera we have also added some modern Dual/Triband fiters designed for narrowband imaging etc

IDAS LPS-D3 RGB - Enhance the contrast of astronomical emission nebulae against a sky with both man-made and natural* sky glow sources, yet preserve the colour balance of broadband objects such as galaxies. As with other IDAS interference filters, the bandpasses are designed to accommodate the steep ray angles of fast optical systems.

IDAS NBZ Ha/O3 HS - The defacto high speed dual-band filter from IDAS, low halo high contrast and works well down to F1.4

IDAS NBZ S2/O3 - This one is new to us also, seemed silly not to fit it for full narrowband imaging however

Bayer Matrix - When you receive your data, at first glance it may appear green, this is normal because One shot colour cameras have a bayer matrix over the sensor, this particular sensor has a RGGB bayer matrix and you will need to de-bayer it as part of your calibration and stacking process in your chosen software.
